Authelia with Docker Compose and Traefik: Lightweight SSO and 2FA

Authelia is a self-hosted authentication and authorization server. It can add a central login and a second factor to web applications through a reverse proxy, and it can act as an OpenID Connect (OIDC) Provider for applications with native SSO support.

This guide builds a small, single-node Authelia deployment with Docker Compose, a file-based user directory, SQLite storage, SMTP notifications, and the Traefik stack used throughout this site. It is a practical fit for a personal server or a small trusted group; it is not a high-availability design.

Changelog

1. What Authelia Does — and What It Does Not Do

Authelia provides two related integration modes:

Both modes can share the same account and second-factor registration. That makes Authelia more useful than a Matrix-only authentication component: one instance can protect dashboards through ForwardAuth and also provide OIDC to services such as Synapse, Forgejo, or other compatible applications.

Authelia strengthens the login path. It does not revoke sessions that an application already issued, repair weak application permissions, replace backups, or make a compromised reverse proxy harmless.

Browser ──HTTPS──> Traefik ──ForwardAuth──> Authelia
                       │                       │
                       │ allowed               ├─ password file
                       ▼                       ├─ TOTP / WebAuthn state
                 protected app                └─ SQLite + SMTP

OIDC-capable app ──redirect──> Authelia ──signed identity──> app

2. Prerequisites and Design Choices

Complete the Traefik v3 and CrowdSec guide first. This article reuses its:

• external Docker network named proxy;
• HTTPS entrypoint named websecure;
• certificate resolver named tls_resolver;
• security-headers@file and crowdsec-bouncer@docker middlewares.

You also need:

• a DNS record such as auth.your-domain.com pointing to the server;
• working SMTP credentials for registration and recovery messages;
• Docker Compose and OpenSSL;
• a password manager and an authenticator or security key.

This guide pins Authelia 4.39.20, the current release tested by the official Synapse integration guide at the time of writing. Review the Authelia releases before changing the pin.

3. Create the Directory Structure

sudo mkdir -p /opt/containers/authelia/{config,data,secrets}
cd /opt/containers/authelia

sudo touch config/configuration.yml config/users_database.yml
sudo chmod 600 config/configuration.yml config/users_database.yml
sudo chmod 700 secrets

The resulting layout is deliberately split by purpose:

/opt/containers/authelia/
├── compose.yml
├── .env
├── config/
│   ├── configuration.yml
│   └── users_database.yml
├── data/
│   └── db.sqlite3             # created by Authelia
└── secrets/
    ├── RESET_PASSWORD_JWT_SECRET
    ├── SESSION_SECRET
    ├── STORAGE_ENCRYPTION_KEY
    └── SMTP_PASSWORD

4. Create the Environment and Secret Files

Create /opt/containers/authelia/.env:

AUTHELIA_HOST=auth.your-domain.com
TZ=Europe/Vienna
PUID=1000
PGID=1000

Replace PUID and PGID with the account that owns the stack:

id -u
id -g

Align the bind-mount ownership with those values (replace 1000:1000 if necessary):

sudo chown -R 1000:1000 config data secrets

Generate the three local cryptographic secrets without printing them to the terminal:

cd /opt/containers/authelia

sudo install -o 1000 -g 1000 -m 600 /dev/null secrets/RESET_PASSWORD_JWT_SECRET
openssl rand -hex 64 | sudo tee secrets/RESET_PASSWORD_JWT_SECRET >/dev/null

sudo install -o 1000 -g 1000 -m 600 /dev/null secrets/SESSION_SECRET
openssl rand -hex 64 | sudo tee secrets/SESSION_SECRET >/dev/null

sudo install -o 1000 -g 1000 -m 600 /dev/null secrets/STORAGE_ENCRYPTION_KEY
openssl rand -hex 64 | sudo tee secrets/STORAGE_ENCRYPTION_KEY >/dev/null

sudo install -o 1000 -g 1000 -m 600 /dev/null secrets/SMTP_PASSWORD
sudo nano secrets/SMTP_PASSWORD

Enter only the SMTP password in the last file. Do not put a trailing explanation or username in it. The -o and -g values must stay aligned with PUID and PGID, otherwise the unprivileged container process cannot read the files.

5. Configure Authelia

Create /opt/containers/authelia/config/configuration.yml:

server:
  address: 'tcp://0.0.0.0:9091/'

log:
  level: 'info'

theme: 'dark'

totp:
  disable: false
  issuer: 'your-domain.com'
  period: 30
  skew: 1

webauthn:
  disable: false
  display_name: 'Your Domain'

identity_validation:
  reset_password:
    jwt_lifespan: '5 minutes'

authentication_backend:
  password_reset:
    disable: false
  refresh_interval: '5 minutes'
  file:
    path: '/config/users_database.yml'
    watch: true
    password:
      algorithm: 'argon2'
      argon2:
        variant: 'argon2id'
        iterations: 3
        memory: 65536
        parallelism: 4
        key_length: 32
        salt_length: 16

access_control:
  default_policy: 'deny'
  rules:
    - domain: 'protected.your-domain.com'
      policy: 'two_factor'

session:
  name: 'authelia_session'
  same_site: 'lax'
  inactivity: '5 minutes'
  expiration: '1 hour'
  remember_me: '1 month'
  cookies:
    - domain: 'your-domain.com'
      authelia_url: 'https://auth.your-domain.com'
      default_redirection_url: 'https://protected.your-domain.com'

regulation:
  max_retries: 3
  find_time: '2 minutes'
  ban_time: '5 minutes'

storage:
  local:
    path: '/data/db.sqlite3'

notifier:
  smtp:
    address: 'submission://mail.your-domain.com:587'
    username: 'authelia@your-domain.com'
    sender: 'Authelia <authelia@your-domain.com>'
    subject: '[Authelia] {title}'

The password, session, reset-token, and storage secrets are intentionally absent. Docker injects them from files in the next section.

Adjust the session cookie domain to the parent domain shared by the portal and protected services. Never set it to a public suffix such as .com. Add one sequential access_control.rules entry per protected host or path; with default_policy: deny, an unlisted destination remains closed.

6. Create the First User

Generate an Argon2id password digest interactively, so the plaintext password does not appear in shell history:

docker run --rm -it authelia/authelia:4.39.20 \
  authelia crypto hash generate argon2

Copy only the resulting $argon2id$... digest into /opt/containers/authelia/config/users_database.yml:

users:
  your-username:
    disabled: false
    displayname: 'Your Name'
    password: '$argon2id$v=19$m=65536,t=3,p=4$REPLACE-WITH-YOUR-DIGEST'
    email: 'you@your-domain.com'
    groups:
      - 'admins'

The username is security-sensitive when an application automatically links OIDC identities to existing accounts. Users must not be allowed to rename themselves to another person’s application username.

7. Create the Docker Compose Stack

Create /opt/containers/authelia/compose.yml:

services:
  authelia:
    image: authelia/authelia:4.39.20
    container_name: authelia
    restart: unless-stopped
    user: '${PUID}:${PGID}'
    environment:
      TZ: ${TZ}
      AUTHELIA_IDENTITY_VALIDATION_RESET_PASSWORD_JWT_SECRET_FILE: /secrets/RESET_PASSWORD_JWT_SECRET
      AUTHELIA_SESSION_SECRET_FILE: /secrets/SESSION_SECRET
      AUTHELIA_STORAGE_ENCRYPTION_KEY_FILE: /secrets/STORAGE_ENCRYPTION_KEY
      AUTHELIA_NOTIFIER_SMTP_PASSWORD_FILE: /secrets/SMTP_PASSWORD
    volumes:
      - ./config:/config:ro
      - ./data:/data
      - ./secrets:/secrets:ro
    networks:
      - proxy
    labels:
      - 'traefik.enable=true'
      - 'traefik.docker.network=proxy'
      - 'traefik.http.routers.authelia.rule=Host(`${AUTHELIA_HOST}`)'
      - 'traefik.http.routers.authelia.entrypoints=websecure'
      - 'traefik.http.routers.authelia.tls.certresolver=tls_resolver'
      - 'traefik.http.routers.authelia.middlewares=security-headers@file,crowdsec-bouncer@docker'
      - 'traefik.http.services.authelia.loadbalancer.server.port=9091'

      # Reusable ForwardAuth middleware. Do not add this middleware to
      # the Authelia portal router itself, or you will create a loop.
      - 'traefik.http.middlewares.authelia.forwardAuth.address=http://authelia:9091/api/authz/forward-auth'
      - 'traefik.http.middlewares.authelia.forwardAuth.trustForwardHeader=true'
      - 'traefik.http.middlewares.authelia.forwardAuth.maxResponseBodySize=8192'
      - 'traefik.http.middlewares.authelia.forwardAuth.authResponseHeaders=Remote-User,Remote-Groups,Remote-Name,Remote-Email'

networks:
  proxy:
    external: true

Validate the rendered Compose model before starting it:

cd /opt/containers/authelia
docker compose config --quiet
docker compose up -d
docker compose logs --tail=100 authelia

The container runs directly as the unprivileged UID/GID from .env; its entrypoint never needs to start as root. It also has no host port and no Docker socket. Traefik reaches it only through the shared proxy network.

8. Protect a Web Service

Add the authelia@docker middleware to an application’s Traefik router and add a matching Authelia access-control rule.

Example labels for protected.your-domain.com:

labels:
  - 'traefik.enable=true'
  - 'traefik.docker.network=proxy'
  - 'traefik.http.routers.protected.rule=Host(`protected.your-domain.com`)'
  - 'traefik.http.routers.protected.entrypoints=websecure'
  - 'traefik.http.routers.protected.tls.certresolver=tls_resolver'
  - 'traefik.http.routers.protected.middlewares=security-headers@file,crowdsec-bouncer@docker,authelia@docker'
  - 'traefik.http.services.protected.loadbalancer.server.port=8080'

The corresponding rule already exists in the sample configuration:

access_control:
  default_policy: 'deny'
  rules:
    - domain: 'protected.your-domain.com'
      policy: 'two_factor'

Restart Authelia after changing the configuration:

docker compose restart authelia
docker compose logs --tail=100 authelia

9. Enroll and Test the Second Factor

1. Open https://protected.your-domain.com in a private browser window.
2. Sign in with the Authelia username and password.
3. Use the portal to register TOTP or a WebAuthn security key.
4. Confirm that the protected service is inaccessible without completing the second factor.
5. Test logout and a new private window; an existing remembered session is not a valid 2FA test.
6. Test the recovery email flow before depending on it.

TOTP is widely compatible. WebAuthn with a hardware security key or platform authenticator is generally more phishing-resistant. Register a second recovery-capable authenticator and store recovery material safely before removing any existing login route.

Useful diagnostics:

curl -fsS https://auth.your-domain.com/api/health
docker compose logs --tail=200 authelia
docker compose exec authelia authelia config validate --config /config/configuration.yml

10. Backups and Recovery

Back up these items together:

• config/configuration.yml and config/users_database.yml;
• the complete secrets/ directory;
• data/db.sqlite3 using an application-consistent snapshot;
• the pinned compose.yml and .env;
• your SMTP and DNS recovery procedure.

An encrypted off-host backup is the real disaster-recovery copy. A second copy on the same filesystem does not protect against disk loss, ransomware, or a destructive administrative error.

11. Safe Upgrades

1. Read the Authelia release notes and configuration changes.
2. Create a consistent, encrypted backup.
3. Change the image pin deliberately; do not switch production to latest.
4. Pull, validate, and recreate the service.
5. Test password login, the second factor, SMTP, ForwardAuth, and every OIDC client.

docker compose pull authelia
docker compose config --quiet
docker compose up -d
docker compose logs --tail=100 authelia

12. Extending Authelia with OIDC

ForwardAuth is only half of the design. Applications with native OIDC support should normally use it, because their browser and API flows remain application-aware.

The next guide applies this to an existing Matrix account without accidentally creating a second Matrix identity: Adding Authelia 2FA to Matrix Synapse with OpenID Connect.

Conclusion

You now have a compact central authentication service that can enforce TOTP or WebAuthn for browser applications and later serve native OIDC clients. The useful security boundary is not the login page alone: keep the Traefik routing, Authelia policy, application permissions, existing sessions, secrets, and backups aligned.
