Deploying a Matrix Synapse Server with Docker and Traefik

This guide will walk you through deploying a powerful, federated Matrix Synapse homeserver. We will use the popular matrix-docker-ansible-deploy playbook, which simplifies the setup of Synapse and its various components, including bridges for other chat platforms.

This setup is designed to integrate seamlessly with an existing Traefik v3 reverse proxy and a root-domain Nginx web server, making it a perfect addition to a modern, container-based infrastructure.

Changelog

1. Prerequisites

1. Traefik v3 and CrowdSec with Docker Compose: A Modern Security Stack: This is the foundation for our reverse proxy and security.
2. Deploying a Secure Nginx Website with Traefik and Docker Compose: This step is crucial as it establishes a web server on your root domain and correctly configures the .well-known/matrix delegation required for federation.

Architecture (simplified)

  Users / Browsers / Homeservers
             │
             ▼
      your-domain.com  ──>  [Nginx](../nginx_webserver/) on root domain
             │                 │
             │                 ├─ Serves your website (/, /assets, ...)
             │                 └─ Serves .well-known/matrix/{server,client}
             │                                  │
             │                                  ▼
             └────────────────────────── delegates to ──> matrix.your-domain.com
                                                       (Synapse via Traefik)
                                                            │
                                                            ▼
                                               Traefik (websecure, synapse)
                                                            │
                                                            ▼
                                                        Synapse

You will also need:

• git, jq, and pwgen for version control, JSON parsing, and password generation.
• Python 3 and pip installed on your server.
• sudo or root access.

Install the required tools:

sudo apt update && sudo apt -y install git jq pwgen python3-pip

2. Directory Structure

First, we’ll create a dedicated directory for the Matrix playbook configuration and files.

sudo mkdir -p /opt/containers/matrix

3. Download the Ansible Playbook

Next, clone the official matrix-docker-ansible-deploy repository from GitHub into the directory you just created.

sudo git clone https://github.com/spantaleev/matrix-docker-ansible-deploy.git /opt/containers/matrix

4. Initial Configuration

The playbook is configured using Ansible variables. We’ll start by creating a configuration directory based on your Matrix server’s hostname and copying the example vars.yml file.

cd /opt/containers/matrix

# Replace 'matrix.your-domain.com' with your actual server name
sudo mkdir -p inventory/host_vars/matrix.your-domain.com
sudo cp examples/vars.yml inventory/host_vars/matrix.your-domain.com/

4.1. Generate Secret Keys

The configuration requires two strong secret keys. You can generate these using pwgen or openssl.

# Generate two strong keys and save them for the next step
pwgen -s 64 1
pwgen -s 64 1

4.2. Customize vars.yml

Now, open the vars.yml file and customize it for your environment. This is the most critical step.

sudo nano inventory/host_vars/matrix.your-domain.com/vars.yml

Below is a complete configuration based on a feature-rich setup. Adjust the values to match your domain, secrets, and desired features.

# The bare domain name which represents your Matrix identity.
matrix_domain: your-domain.com
matrix_homeserver_implementation: synapse
matrix_homeserver_generic_secret_key: 'PASTE-YOUR-GENERIC-SECRET-KEY-HERE'

# Use our own Traefik (externally managed)
matrix_playbook_reverse_proxy_type: other-traefik-container
traefik_certs_dumper_enabled: false
traefik_config_certificatesResolvers_acme_email: 'your-email@example.com'

postgres_connection_password: 'PASTE-YOUR-POSTGRES-PASSWORD-HERE'
devture_systemd_docker_base_docker_service_name: "docker"
matrix_playbook_docker_installation_enabled: false

# We delegate .well-known from the root domain via Nginx
matrix_static_files_enabled: false
matrix_static_files_container_labels_traefik_enabled: false

matrix_coturn_enabled: false

# Traefik integration
matrix_playbook_reverse_proxy_container_network: proxy
matrix_playbook_reverse_proxy_hostname: traefik
matrix_federation_traefik_entrypoint_name: synapse

# Disable Synapse's internal client-API router (or redirect to a valid entrypoint)
matrix_synapse_reverse_proxy_companion_container_labels_internal_client_api_enabled: false
matrix_synapse_reverse_proxy_companion_container_labels_internal_client_api_traefik_entrypoints: websecure

# --- Core services ---
matrix_synapse_container_labels_traefik_docker_network: proxy
matrix_synapse_container_labels_traefik_entrypoints: websecure
matrix_synapse_container_labels_traefik_tls_certResolver: tls_resolver
matrix_synapse_container_labels_traefik_middlewares: 'security-headers@file,crowdsec-bouncer@docker'

matrix_client_element_container_labels_traefik_docker_network: proxy
matrix_client_element_container_labels_traefik_entrypoints: websecure
matrix_client_element_container_labels_traefik_tls_certResolver: tls_resolver
matrix_client_element_container_labels_traefik_middlewares: 'security-headers@file,crowdsec-bouncer@docker'

matrix_admin: '@your-username:your-domain.com'

matrix_sliding_sync_enabled: true
matrix_sliding_sync_container_labels_traefik_docker_network: proxy
matrix_sliding_sync_container_labels_traefik_entrypoints: websecure
matrix_sliding_sync_container_labels_traefik_tls_certResolver: tls_resolver
matrix_sliding_sync_container_labels_traefik_middlewares: 'security-headers@file,crowdsec-bouncer@docker'

matrix_synapse_admin_enabled: true
matrix_synapse_admin_container_http_host_bind_port: ""
matrix_synapse_admin_container_labels_traefik_docker_network: proxy
matrix_synapse_admin_container_labels_traefik_entrypoints: websecure
matrix_synapse_admin_container_labels_traefik_tls_certResolver: tls_resolver
matrix_synapse_admin_container_labels_traefik_middlewares: 'security-headers@file,crowdsec-bouncer@docker'

# E-Mail relay (optional)
exim_relay_sender_address: "matrix@your-domain.com"
exim_relay_relay_use: true
exim_relay_relay_host_name: "mail.your-domain.com"
exim_relay_relay_host_port: 587
exim_relay_relay_auth: true
exim_relay_relay_auth_username: "user@your-domain.com"
exim_relay_relay_auth_password: "YOUR-EMAIL-PASSWORD"

matrix_appservice_double_puppet_enabled: true

# --- Bridges ---
# The playbook can install and configure various bridges to connect your Matrix homeserver
# to other chat networks like Telegram, Discord, Signal, etc. When enabling a bridge,
# it is crucial to provide the `homeserver` configuration block to ensure it communicates
# correctly with Synapse via Traefik. For more details on available bridges and their
# specific configurations, refer to the official documentation.

# Telegram – Correct EntryPoints + specify Homeserver
matrix_mautrix_telegram_enabled: true
matrix_mautrix_telegram_api_id: 12345678
matrix_mautrix_telegram_api_hash: 'your_telegram_api_hash'
matrix_mautrix_telegram_container_labels_traefik_entrypoints: websecure
matrix_mautrix_telegram_container_labels_public_endpoint_traefik_entrypoints: websecure
matrix_mautrix_telegram_container_labels_metrics_traefik_entrypoints: websecure
matrix_mautrix_telegram_configuration_extension_yaml: |
  homeserver:
    address: "https://matrix.your-domain.com"
    domain: "your-domain.com"
  bridge:
    permissions:
      '{{ matrix_admin }}': admin

# Meta Messenger
matrix_mautrix_meta_messenger_enabled: true
matrix_mautrix_meta_messenger_configuration_extension_yaml: |
  homeserver:
    address: "https://matrix.your-domain.com"
    domain: "your-domain.com"
  bridge:
    permissions:
      '*': relay
      'your-domain.com': admin
      '{{ matrix_admin }}': admin

# Discord – Correct Avatar-Proxy & general EntryPoints
matrix_mautrix_discord_enabled: true
matrix_mautrix_discord_container_labels_traefik_entrypoints: websecure
matrix_mautrix_discord_container_labels_avatar_proxy_traefik_entrypoints: websecure
matrix_mautrix_discord_configuration_extension_yaml: |
  homeserver:
    address: "https://matrix.your-domain.com"
    domain: "your-domain.com"

# --- Element Call / Livekit ---
matrix_element_call_enabled: true
matrix_element_call_container_labels_traefik_entrypoints: websecure
matrix_element_call_container_labels_traefik_tls_certResolver: tls_resolver
matrix_element_call_container_labels_traefik_docker_network: proxy

matrix_livekit_jwt_service_container_labels_traefik_entrypoints: websecure
matrix_livekit_jwt_service_container_labels_traefik_tls_certResolver: tls_resolver
matrix_livekit_jwt_service_container_labels_traefik_docker_network: proxy

livekit_server_container_labels_traefik_entrypoints: websecure
livekit_server_container_labels_public_metrics_traefik_tls_certResolver: tls_resolver
livekit_server_container_labels_traefik_docker_network: proxy

5. Install Ansible and Dependencies

This playbook uses Ansible to automate the setup. Choose the installation method that fits your distribution policy.

For Debian 12 (system pip with –break-system-packages)

# Ensure pip is available
sudo apt install -y python3-pip

# Install Ansible and required Python packages system-wide
pip3 install --break-system-packages ansible docker passlib

For Other Linux Distributions (recommended: Python virtual environment)

# Create and activate a dedicated virtual environment
python3 -m venv ~/.venvs/matrix-ansible
source ~/.venvs/matrix-ansible/bin/activate

# Upgrade pip and install required packages in the venv
pip install --upgrade pip
pip install ansible docker passlib

Next, install the Ansible roles required by the playbook:

cd /opt/containers/matrix
make roles

6. Configure Ansible Hosts

Now, we need to tell Ansible which server to configure. Since we are running it locally, the setup is simple.

# Copy the example hosts file
sudo cp examples/hosts inventory/hosts

# Edit the file
sudo nano inventory/hosts

Modify the file to look like this. The ansible_connection=local tells Ansible to run all commands on the machine it’s currently on, instead of connecting to a remote server via SSH. Because of this, ansible_host=127.0.0.1 (localhost) is the correct value. Parameters like ansible_ssh_user=root are ignored in this mode, as the playbook runs with the permissions of the user executing it (in our case, root via sudo).

[matrix_servers]
matrix.your-domain.com ansible_host=127.0.0.1 ansible_connection=local

7. Adjust Traefik for Federation

For Matrix federation to work, other servers need to connect to yours on port 8448. We must expose this port in our main Traefik stack and create a dedicated entrypoint for it.

Go to your Traefik stack’s directory (e.g., /opt/containers/traefik-stack).

7.1. Expose Federation Port

Edit your main docker-compose.yml:

sudo nano docker-compose.yml

Add port 8448 to the ports section of the traefik service:

services:
  traefik:
    # ... other settings
    ports:
      - "80:80"
      - "443:443"
      - "8448:8448" # Add this line for Matrix federation
    # ... rest of the settings

7.2. Create Federation and Internal Entrypoints

Edit your static Traefik configuration (traefik/config/traefik.yml):

sudo nano traefik/config/traefik.yml

Add a new synapse entrypoint for federation and a matrix-internal-matrix-client-api entrypoint for internal communication.

For recent playbook versions, it is recommended to also define the internal matrix-internal-matrix-client-api entrypoint on port 8008. This port is not published to the host and serves as an internal C2S route for bridges and add-ons, preventing errors in the Traefik dashboard.

entryPoints:
  web:
    address: ":80"
    # ...
  websecure:
    address: ":443"
  synapse: # For federation
    address: ":8448"
  matrix-internal-matrix-client-api: # For internal C2S communication
    address: ":8008"

7.3. Restart Traefik

Apply the changes by restarting your Traefik stack:

cd /opt/containers/traefik-stack
docker compose up -d

8. Run the Matrix Installation

With all the configuration in place, we can now run the Ansible playbook to set up and install everything.

cd /opt/containers/matrix
sudo ansible-playbook -i inventory/hosts setup.yml --tags=setup-all

This command will download all necessary Docker images, generate configuration files, and prepare the services. It may take several minutes.

9. Start the Matrix Services

Once the setup is complete, start all the Matrix containers:

sudo ansible-playbook -i inventory/hosts setup.yml --tags=start

After a few moments, all the services you enabled should be running. You can verify this with docker ps.

10. Verify the Installation

After starting the services, it’s crucial to verify that all components are running and communicating correctly.

10.1. Check Running Containers

First, ensure all enabled services are running. The exact names will vary based on your matrix_domain.

docker ps --format '{{.Names}}' | grep -E 'synapse|element|sliding|admin'

10.2. Verify .well-known Delegation (CLI)

Check if your Nginx server is correctly serving the delegation files for your root domain.

# Replace 'your-domain.com' with your actual domain
curl -s https://your-domain.com/.well-known/matrix/server | jq
curl -s https://your-domain.com/.well-known/matrix/client | jq

Both commands should return a clean JSON output pointing to matrix.your-domain.com.

10.3. Verify Federation Endpoint (CLI)

Test if the Synapse federation port (8448) is correctly exposed through Traefik.

# Replace 'matrix.your-domain.com' with your actual matrix subdomain
curl -sS https://matrix.your-domain.com:8448/_matrix/federation/v1/version | jq

This should return a JSON object with server information, confirming the federation endpoint is reachable.

10.4. Verify CrowdSec Bouncer Registration

Check if the CrowdSec bouncer for Traefik has successfully registered with the CrowdSec agent.

cd /opt/containers/traefik-stack
docker compose exec crowdsec cscli bouncers list

You should see the Traefik bouncer in the list with a valid status.

10.5. Web-based Federation Test

Finally, use the official Federation Tester for a comprehensive check.

1. Go to: https://federationtester.matrix.org/
2. Enter your server name (e.g., your-domain.com) and run the test.

If everything is configured correctly, you should see a success message.

11. Create Your First User

Use the playbook to register your administrator user.

cd /opt/containers/matrix
sudo ansible-playbook -i inventory/hosts setup.yml --tags=register-user -e 'username=your-username' -e 'admin=yes'

You can re-run this command with admin=no to create non-admin users.

12. Log In with Element

Your homeserver is now ready! You can access the Element web client by navigating to https://matrix.your-domain.com.

1. Click “Sign In”.
2. Your homeserver should be pre-filled. If not, edit it to show your server’s address (matrix.your-domain.com).
3. Log in with the username and password you just created.

13. Accessing the Synapse Admin UI

Because we set matrix_synapse_admin_enabled: true in our vars.yml configuration, a powerful web-based administration interface for Synapse is automatically deployed. This UI is essential for server maintenance and user management.

You can access it at: https://matrix.your-domain.com/synapse-admin

Log in with your Matrix administrator account. From here, you can:

• Manage users (deactivate, make admin, etc.).
• View server statistics and metrics.
• Explore rooms and manage their settings.

This interface is the primary tool for the day-to-day administration of your homeserver.

14. Maintenance

Updating Matrix

To update your Matrix server and its components to the latest version:

cd /opt/containers/matrix

# Pull the latest changes from the git repository
sudo git pull

# It's a good practice to review the CHANGELOG.md for breaking changes
# sudo nano CHANGELOG.md

# Re-run the setup and start tags to apply updates
sudo ansible-playbook -i inventory/hosts setup.yml --tags=setup-all,start

Stopping and Uninstalling

To stop all Matrix services:

cd /opt/containers/matrix
sudo ansible-playbook -i inventory/hosts setup.yml --tags=stop

To completely uninstall and delete all data:

cd /opt/containers/matrix
sudo ansible-playbook -i inventory/hosts setup.yml --tags=uninstall

15. Troubleshooting

Below are common issues and quick checks to resolve them.

15.1 Federation test fails

• Ensure port 8448 is exposed by Traefik and the synapse entrypoint exists.

cd /opt/containers/traefik-stack
docker compose ps traefik
docker inspect traefik | jq '.[0].NetworkSettings.Ports["8448/tcp"]'

• Test the federation version endpoint directly:

curl -sS https://matrix.your-domain.com:8448/_matrix/federation/v1/version | jq

15.2 .well-known is invalid or missing

• Verify the .well-known delegation from your root domain (served by Nginx server):

curl -s https://your-domain.com/.well-known/matrix/server | jq
curl -s https://your-domain.com/.well-known/matrix/client | jq

• Re-check that the placeholders in conf/nginx.conf were replaced via sed and that CORS headers middleware uses camelCase keys in Traefik labels (e.g., accessControlAllowOriginList).

15.3 Traefik/CrowdSec middleware not applied

• Ensure you reference providers correctly:
  • Security headers: security-headers@file
  • CrowdSec bouncer: crowdsec-bouncer@docker

15.4 ACME/TLS issues

• Inspect Traefik logs for ACME errors and DNS problems:

docker compose logs -n 200 traefik | tail -n 200

• Confirm A/AAAA records for traefik.your-domain.com and matrix.your-domain.com point to your server and that port 443 is reachable.
• Disable CDN Proxy for Initial Certificate: If you are using a CDN like Cloudflare, ensure the proxy is disabled (set to “DNS Only” or “grey cloud”) for your domains during the first certificate request. The HTTP-01 challenge requires Let’s Encrypt to reach your server directly. You can re-enable the proxy after the certificate is issued.

15.5 Docker network not found

• Make sure the external proxy network exists and is used by all services behind Traefik:

docker network ls | grep proxy || docker network create proxy

15.6 Permission problems in inventory/host_vars

• If editing files is cumbersome, you can align ownership (optional):

sudo chown -R "$USER":"$USER" /opt/containers/matrix/inventory

15.7 Ansible/venv not active

• If you installed Ansible in a virtualenv, reactivate it before running playbooks:

source ~/.venvs/matrix-ansible/bin/activate

15.8 CrowdSec bouncer not registered

• Check the bouncer status inside the CrowdSec container (run in your Traefik stack directory):

docker compose exec crowdsec cscli bouncers list

Conclusion

You now have a fully functional, federated Matrix Synapse homeserver integrated with your Traefik proxy and Nginx web server. This powerful setup not only gives you control over your own secure communications but is also extensible with numerous bridges and features, allowing you to create a central hub for all your chat services.

📚PLAYBOOK DOCUMENTATION 🛡️MATRIX DOCUMENTATION
