Secure Server-to-Server File Transfers with rsync and tmux

This guide provides a definitive, “terminal-first” approach to transferring large amounts of data directly between two remote servers. By combining the power of rsync for data synchronization, tmux for session persistence, and a securely configured SSH deploy key for authentication, you can create a “fire-and-forget” transfer process that is robust, efficient, and secure.

This method avoids routing traffic through your local machine, saving you bandwidth and making the process immune to local network disconnects.

Changelog

1. The Goal: Direct, Robust Server-to-Server Transfers

Before we begin, it’s essential to understand the data flow we are building.

2. Prerequisites

• You have key-based SSH access from your local computer to two Linux servers, Server1 and Server2.
• Password authentication on your servers is (correctly) disabled.
• You have sudo or root privileges on Server1 to install software.

Local SSH Configuration (For Your Convenience)

Define aliases for your servers in your local computer’s ~/.ssh/config file. This only makes it easier for you to connect; it does not affect the servers themselves.

# In ~/.ssh/config on your LOCAL machine
Host Server1
    HostName cloud.server1.xyz
    User your_user

Host Server2
    HostName cloud.server2.xyz
    User root
    Port 2222 # Use your actual port

3. The Core Method: Building the Key Infrastructure

This is the most critical part of the tutorial. We will:

1. Create a deploy key on Server1.
2. Configure the SSH client on Server1 so it knows how to find Server2.
3. Use our local PC as a trusted intermediary to securely install and restrict the key on Server2.

3.1. On Server1: Create the Deploy Key

# On your local machine, connect to Server1
ssh Server1

# Now, on Server1, generate a new, passwordless SSH key pair
# When prompted for a passphrase, press Enter twice to leave it empty.
ssh-keygen -t ed25519 -f ~/.ssh/id_deploy_to_server2 -C "rsync deploy key for server2"

3.2. On Server1: Configure its SSH Client

We must teach Server1 how to connect to Server2. We do this by creating a config file in its .ssh directory.

# On Server1, create and open the config file
nano ~/.ssh/config

Add the following configuration. Replace the values with the actual connection details for Server2.

Host Server2
    HostName cloud.server2.xyz
    User root
    Port 2222
    IdentityFile ~/.ssh/id_deploy_to_server2

• IdentityFile: This line is key. It tells Server1’s SSH client: “When connecting to the host aliased as ‘Server2’, always use this specific private key.”

Save the file (Ctrl+X, then Y, then Enter) and set the correct permissions:

# On Server1
chmod 600 ~/.ssh/config

3.3. On Server1: Copy the Public Key for Transfer

Display the public key so you can copy it to your clipboard.

# On Server1
cat ~/.ssh/id_deploy_to_server2.pub

Action: Mark and copy the entire output (the line starting ssh-ed25519 AAAA...). Then, log out from Server1.

exit

3.4. From Your Local PC: Install and Restrict the Key on Server2

# 1. On your local PC, append the key to Server2's authorized_keys.
#    Replace 'PASTE_KEY_FROM_CLIPBOARD_HERE' with the key you just copied.
ssh Server2 "echo 'PASTE_KEY_FROM_CLIPBOARD_HERE' >> ~/.ssh/authorized_keys"

# 2. Now, SSH to Server2 to restrict the key.
ssh Server2

# 3. Once on Server2, open the file for editing.
nano ~/.ssh/authorized_keys

In the editor, find the key you just added at the bottom of the file. Navigate to the very beginning of that line and prepend the command restriction.

Before:

ssh-ed25519 AAAA... rsync deploy key for server2

After (replace /path/to/destination/ with your actual path!):

command="rsync --server -vlogDtpre.iL --partial . /path/to/destination/",no-port-forwarding,no-x11-forwarding,no-agent-forwarding,no-pty ssh-ed25519 AAAA... rsync deploy key for server2

Save the file and exit the editor (Ctrl+X, then Y, then Enter).

4. Test the Connection and Launch the Transfer

4.1. Test the Inter-Server Connection

This test now verifies that the new configuration on Server1 is working correctly.

# On your local PC
ssh Server1

# Now, on Server1, this command will work because of the new ~/.ssh/config
ssh Server2

4.2. Launch the Uninterruptible Transfer

# On Server1, install tmux if you haven't already
sudo apt update && sudo apt install tmux

# Start a new tmux session
tmux new -s syncJob

# Inside the tmux session, execute the now-simplified rsync command.
# No -e option is needed because Server1's SSH client is now configured!
rsync -avh --info=progress2 --partial \
  /path/to/source/ \
  Server2:/path/to/destination/

4.3. Detach and Disconnect

The process is now running. Detach from the tmux session and log out.

Ctrl+b, then d

# On Server1
exit

5. Managing the rsync Session

You can check on, re-attach, or terminate your transfer at any time.

• To check the progress: ssh Server1 and then tmux attach -t syncJob.
• To kill the session: ssh Server1 and then tmux kill-session -t syncJob.

6. Quick Troubleshooting

7. Conclusion

By following this definitive guide, you have built a powerful and professionally architected data transfer system. The key was configuring the client (Server1) to know how to reach the target (Server2), a fundamental concept for any automated inter-server task. This setup is ideal for large backups, data migrations, and any scenario where a direct, robust, server-to-server connection is required.
