Traefik v3 and CrowdSec with Docker Compose: A Modern Security Stack

This guide provides a streamlined approach to deploying a powerful and secure web stack using Traefik as a reverse proxy and CrowdSec for threat protection. We will use Docker Compose to orchestrate the services, creating a setup that is easy to manage, scale, and maintain.

Changelog

1. Prerequisites

Before you begin, ensure you have the following installed on your server (e.g., Ubuntu 22.04 or Debian 12):

• Docker and Docker Compose
• curl, openssl, and apache2-utils (for password generation)
• A domain name pointed to your server’s IP address
• Open firewall ports 80 and 443
• sudo or root access

You can install the required utilities with:

sudo apt update
sudo apt install -y curl openssl apache2-utils

2. Directory Structure

A well-organized directory structure is key. We will create a central location for our stack’s configuration and data.

# Create the main directory
sudo mkdir -p /opt/containers/traefik-stack
cd /opt/containers/traefik-stack

# Create directories for each service
sudo mkdir -p traefik/{dynamic,logs,certs}
sudo mkdir -p crowdsec/{config,data}

# Prepare Let's Encrypt certificates file
sudo touch traefik/certs/acme.json
sudo chmod 600 traefik/certs/acme.json

This structure keeps everything tidy and separated.

3. Configuration Files

Now, let’s create the configuration files for our stack.

3.1. Main Configuration (.env)

This file holds all your environment-specific variables.

sudo tee .env > /dev/null << 'EOF'
# --- General Settings ---
TZ=Europe/Berlin
DOMAIN_NAME=your-domain.com

# --- Traefik Settings ---
TRAEFIK_DASHBOARD_HOST=traefik.${DOMAIN_NAME}
LETSENCRYPT_EMAIL=your-email@example.com

# --- CrowdSec Settings ---
CROWDSEC_COLLECTIONS="crowdsecurity/traefik crowdsecurity/linux"

# --- Credentials ---
CROWDSEC_BOUNCER_API_KEY=PASTE-YOUR-GENERATED-KEY-HERE
EOF

3.2. Traefik Static Configuration (traefik.yml)

This file contains the core Traefik settings that rarely change.

sudo tee traefik.yml > /dev/null << 'EOF'
global:
  checkNewVersion: true
  sendAnonymousUsage: false

api:
  dashboard: true

ping: {}

entryPoints:
  web:
    address: ":80"
    http:
      redirections:
        entryPoint:
          to: websecure
          scheme: https
    forwardedHeaders:
      insecure: false
      trustedIPs:
        - "127.0.0.1/32"
        - "10.0.0.0/8"
        - "172.16.0.0/12"
        - "192.168.0.0/16"
  websecure:
    address: ":443"
    forwardedHeaders:
      insecure: false
      trustedIPs:
        - "127.0.0.1/32"
        - "10.0.0.0/8"
        - "172.16.0.0/12"
        - "192.168.0.0/16"

providers:
  docker:
    endpoint: "unix:///var/run/docker.sock"
    exposedByDefault: false
  file:
    directory: /etc/traefik/dynamic
    watch: true

experimental:
  plugins:
    crowdsec-bouncer:
      moduleName: github.com/maxlerebourg/crowdsec-bouncer-traefik-plugin
      version: v1.4.7

certificatesResolvers:
  tls_resolver:
    acme:
      storage: /certs/acme.json
      httpChallenge:
        entryPoint: web

log:
  level: INFO
  filePath: /var/log/traefik/traefik.log
accessLog:
  filePath: /var/log/traefik/access.log
  format: json
  filters:
    statusCodes:
      - "400-599"
  fields:
    headers:
      defaultMode: keep
EOF

3.2.1. Forwarded Headers (Trusted IPs)

Traefik acts as a reverse proxy in front of your applications. To ensure your apps see the real client IP (and not the internal Docker gateway IP), Traefik must correctly process the X-Forwarded-For header.

Without this configuration, any visitor can spoof the X-Forwarded-For header, bypassing IP-based rate limiting, abuse protection, or geo-blocking.

What do these entries in traefik.yml mean?

• insecure: false — Traefik does not automatically trust all incoming X-Forwarded-For headers. This is the default, but we set it explicitly for clarity.
• trustedIPs — Traefik only accepts the forwarded header from these source IPs. For all other requests, Traefik overwrites the header with the actual sender IP.
• The four ranges cover the loopback interface (127.0.0.1) and all private network ranges (used for internal Docker communication).

3.3. Traefik Dynamic Configuration (dynamic/middlewares.yml)

This file defines reusable middleware components.

sudo tee traefik/dynamic/middlewares.yml > /dev/null << 'EOF'
http:
  middlewares:
    # 1. General security headers
    security-headers:
      headers:
        browserXssFilter: true
        contentTypeNosniff: true
        frameDeny: true
        forceSTSHeader: true
        stsIncludeSubdomains: true
        stsPreload: true
        stsSeconds: 31536000

    # 2. Basic Auth for the dashboard
    traefik-dashboard-auth:
      basicAuth:
        usersFile: "/etc/traefik/dynamic/.htpasswd"
EOF

3.4. Docker Compose (docker-compose.yml)

This is the main file defining our services.

sudo tee docker-compose.yml > /dev/null << 'EOF'
services:
  traefik:
    image: traefik:v3.6
    container_name: traefik
    restart: unless-stopped
    ports:
      - "80:80"
      - "443:443"
    command:
      - --certificatesresolvers.tls_resolver.acme.email=${LETSENCRYPT_EMAIL}
    networks:
      - proxy
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./traefik.yml:/etc/traefik/traefik.yml:ro
      - ./traefik/dynamic:/etc/traefik/dynamic:ro
      - ./traefik/certs:/certs
      - ./traefik/logs:/var/log/traefik
    environment:
      - TZ=${TZ}
    labels:
      - "traefik.enable=true"
      - "traefik.http.middlewares.crowdsec-bouncer.plugin.crowdsec-bouncer.crowdsecMode=stream"
      - "traefik.http.middlewares.crowdsec-bouncer.plugin.crowdsec-bouncer.crowdsecLapiHost=crowdsec:8080"
      - "traefik.http.middlewares.crowdsec-bouncer.plugin.crowdsec-bouncer.crowdsecLapiKey=${CROWDSEC_BOUNCER_API_KEY}"
      - "traefik.http.routers.dashboard.rule=Host(`${TRAEFIK_DASHBOARD_HOST}`)"
      - "traefik.http.routers.dashboard.entrypoints=websecure"
      - "traefik.http.routers.dashboard.tls.certresolver=tls_resolver"
      - "traefik.http.routers.dashboard.service=api@internal"
      - "traefik.http.routers.dashboard.middlewares=traefik-dashboard-auth@file,crowdsec-bouncer@docker"
    healthcheck:
      test: ["CMD", "traefik", "healthcheck", "--ping"]
      interval: 30s
      timeout: 10s
      retries: 3

  crowdsec:
    image: crowdsecurity/crowdsec:latest
    container_name: crowdsec
    restart: unless-stopped
    networks:
      - proxy
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./crowdsec/config:/etc/crowdsec:z
      - ./crowdsec/data:/var/lib/crowdsec/data:z
      - ./traefik/logs:/var/log/traefik:ro
      - /var/log:/var/log/host/:ro
    environment:
      - TZ=${TZ}
      - COLLECTIONS=${CROWDSEC_COLLECTIONS}
    healthcheck:
      test: ["CMD", "cscli", "version"]
      interval: 60s
      timeout: 15s
      retries: 3

networks:
  proxy:
    name: proxy
    external: true
EOF

3.5. Create Dashboard Password

sudo htpasswd -c traefik/dynamic/.htpasswd admin

3.6. CrowdSec Acquisition Configuration (crowdsec/config/acquis.yaml)

sudo tee crowdsec/config/acquis.yaml > /dev/null << 'EOF'
filenames:
  - /var/log/traefik/access.log
labels:
  type: traefik
---
filenames:
  - /var/log/host/auth.log
  - /var/log/host/syslog
labels:
  type: syslog
EOF

4. Launch and Verify the Stack

1. Create the external network:

   docker network create proxy

2. Start the services:

   docker compose up -d

   Upon first launch, Traefik will request a certificate from Let’s Encrypt. This may take a minute.
3. Generate the Bouncer API Key:

   docker compose exec crowdsec cscli bouncers add traefik -o raw

   ℹ️ LAPI STARTUP TIME

   Upon the very first start, CrowdSec might take a few moments to initialize the Local API (LAPI). If you get a connection error, wait 10-20 seconds and try the command again.

   Copy the long, alphanumeric string that is output.
4. Update your .env file: Paste the copied key as the value for CROWDSEC_BOUNCER_API_KEY.
5. Restart Traefik to apply the key:

   docker compose up -d --force-recreate traefik

6. Verify the bouncer connection:

   docker compose exec crowdsec cscli bouncers list

   You should see the traefik bouncer listed. You can now access your dashboard at https://traefik.your-domain.com.

5. Adding Services to Traefik

Here is how to expose other Docker services through Traefik, with and without CrowdSec protection.

5.1. Scenario 1: Service Protected by CrowdSec (Standard)

This is the recommended setup for most public-facing services. We’ll use WordPress as an example. Create a docker-compose.yml in a separate directory (e.g., /opt/containers/wordpress):

services:
  wordpress:
    image: wordpress:latest
    restart: unless-stopped
    networks:
      - default
      - proxy
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.wordpress.rule=Host(`blog.your-domain.com`)"
      - "traefik.http.routers.wordpress.entrypoints=websecure"
      - "traefik.http.routers.wordpress.tls.certresolver=tls_resolver"
      - "traefik.http.routers.wordpress.middlewares=security-headers@file,crowdsec-bouncer@docker"
      - "traefik.http.services.wordpress.loadbalancer.server.port=80"

  db:
    image: mariadb:11
    restart: unless-stopped
    environment:
      MYSQL_ROOT_PASSWORD: change-me
      MYSQL_DATABASE: wordpress
      MYSQL_USER: wordpress
      MYSQL_PASSWORD: supersecret
    volumes:
      - db_data:/var/lib/mysql
    networks:
      - default

networks:
  proxy:
    external: true
  default:

volumes:
  db_data:

The key label is traefik.http.routers.wordpress.middlewares=security-headers@file,crowdsec-bouncer@docker, which applies our security headers (from the file provider) and the CrowdSec bouncer (defined on the Traefik service via Docker labels).

5.2. Scenario 2: Service Bypassing CrowdSec (Special Case)

Sometimes you need to expose a service without CrowdSec’s interference. Common reasons include:

• A public API that must not be blocked.
• A site heavily reliant on ad network traffic, where false positives could impact revenue.
• Internal tools that are already secured by other means.

To bypass CrowdSec, simply omit the crowdsec-bouncer@docker middleware.

# In the labels for your service (e.g., an API)
labels:
  - "traefik.enable=true"
  - "traefik.http.routers.my-api.rule=Host(`api.your-domain.com`)"
  - "traefik.http.routers.my-api.entrypoints=websecure"
  - "traefik.http.routers.my-api.tls.certresolver=tls_resolver"
  # --- Middlewares (Security ONLY) ---
  - "traefik.http.routers.my-api.middlewares=security-headers@file"
  - "traefik.http.services.my-api.loadbalancer.server.port=3000"

5.3. Routing Multiple (Sub)Domains to One Service

Sometimes one container should respond to more than one hostname (e.g., example.com and www.example.com, or multiple subdomains pointing to the same app). You have a few common options.

Option A: Multiple Explicit Hosts in One Router

labels:
  - "traefik.enable=true"
  - "traefik.http.routers.app.rule=Host(`example.com`) || Host(`www.example.com`)"
  - "traefik.http.routers.app.entrypoints=websecure"
  - "traefik.http.routers.app.tls.certresolver=tls_resolver"
  - "traefik.http.routers.app.middlewares=security-headers@file,crowdsec-bouncer@docker"
  - "traefik.http.services.app.loadbalancer.server.port=80"

Option B: Wildcard / Pattern Matching (Many Subdomains)

Use this if you want to match many subdomains dynamically.

labels:
  - "traefik.enable=true"
  - "traefik.http.routers.app.rule=HostRegexp(`[a-z0-9-]+\.example\.com`)"
  - "traefik.http.routers.app.entrypoints=websecure"
  - "traefik.http.routers.app.tls.certresolver=tls_resolver"
  - "traefik.http.routers.app.middlewares=security-headers@file,crowdsec-bouncer@docker"
  - "traefik.http.services.app.loadbalancer.server.port=80"

Option C: Multiple Routers, One Service (Different Middleware per Host)

This is useful if one hostname should bypass CrowdSec while another one stays protected.

labels:
  - "traefik.enable=true"

  - "traefik.http.routers.app-main.rule=Host(`app.example.com`)"
  - "traefik.http.routers.app-main.entrypoints=websecure"
  - "traefik.http.routers.app-main.tls.certresolver=tls_resolver"
  - "traefik.http.routers.app-main.middlewares=security-headers@file,crowdsec-bouncer@docker"

  - "traefik.http.routers.app-api.rule=Host(`api.example.com`)"
  - "traefik.http.routers.app-api.entrypoints=websecure"
  - "traefik.http.routers.app-api.tls.certresolver=tls_resolver"
  - "traefik.http.routers.app-api.middlewares=security-headers@file"

  - "traefik.http.services.app.loadbalancer.server.port=80"
  - "traefik.http.routers.app-main.service=app"
  - "traefik.http.routers.app-api.service=app"

6. Maintenance

To update your stack to the latest container images:

cd /opt/containers/traefik-stack
docker compose pull
docker compose up -d --remove-orphans

6.1. Log Rotation (Critical for Production)

Docker Global Log Rotation

Configure Docker to automatically rotate all container logs by editing /etc/docker/daemon.json:

sudo tee /etc/docker/daemon.json > /dev/null << 'EOF'
{
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "10m",
    "max-file": "3"
  }
}
EOF

Apply the changes:

sudo systemctl restart docker
docker info | grep -A3 "Logging Driver"

Traefik Host Log Rotation

Since Traefik writes logs directly to the host filesystem, use logrotate.

sudo tee /etc/logrotate.d/traefik > /dev/null << 'EOF'
/opt/containers/traefik-stack/traefik/logs/*.log {
  daily
  rotate 7
  compress
  delaycompress
  missingok
  notifempty
  copytruncate
  maxsize 50M
}
EOF

Verify Log Rotation

To ensure your rotation is working correctly and to troubleshoot issues, use these commands:

# Debug: show which rules would apply without actually rotating
sudo logrotate -d /etc/logrotate.d/traefik

# Force rotation: execute immediately
sudo logrotate -f /etc/logrotate.d/traefik

# Check rotation status: see when logs were last rotated
sudo cat /var/lib/logrotate/status | grep "traefik"

7. Troubleshooting: Disk Full

If your server runs out of disk space, logs are usually the culprit. Here’s how to diagnose and fix it.

7.1. Identify the Problem

# Quick overview
df -h

# Find large directories
du -h -d1 / 2>/dev/null | sort -h
du -h -d1 /var | sort -h
du -h -d1 /opt | sort -h

# Docker-specific
du -h -d1 /var/lib/docker | sort -h
du -h -d1 /var/lib/docker/containers | sort -h

# Find large container logs
find /var/lib/docker/containers -name '*-json.log' -exec du -h {} \; | sort -h

# Check journald (usually not the problem)
journalctl --disk-usage

7.2. Emergency Cleanup

Truncate Docker container logs:

sudo find /var/lib/docker/containers -name '*-json.log' -exec truncate -s 0 {} \;

Clear Traefik logs:

cd /opt/containers/traefik-stack
docker compose down
rm -rf traefik/logs/*
docker compose up -d

After cleanup, immediately configure log rotation as described in section 6.1 to prevent recurrence.

Conclusion

You now have a modern, secure, and flexible reverse proxy setup. Traefik handles routing and TLS termination effortlessly, while CrowdSec provides a powerful, community-driven security layer. By managing middlewares on a per-service basis, you can tailor the level of protection to fit the exact needs of each application you deploy.

As a next step, you might want to explore the AppSec (WAF) capabilities of the CrowdSec Bouncer plugin, which adds application-level protection against advanced attacks like SQL injection and Cross-Site Scripting directly at the Traefik layer.

📚TRAEFIK DOCUMENTATION 🛡️CROWDSEC DOCUMENTATION
